V-381| 41x45 two story house plans 2800 Sq Ft| custom 5 bedroom duplex modern home plans, 3 bathroom and office with garage













V-381| 41x45 two story house plans 2800 Sq Ft| custom 5 bedroom duplex modern home plans, 3 bathroom and office with garage

* General Notes:

1- The Dimensions and Measurements available in Both Unites (Feet) and (Meters).

2- You will get TWO SETS of Drawings in PDF Files in A3 Paper Size first in (Feet) and Second in (Meters).

3- The Drawings Drawn to SCALE by using Computer and Ready for Instant download.

4- This House plans can be customized, Please Tell us about your desired changes.

5- To View The House Plans in The Metric Dimensions visit our site: www.Panorama99.com

--------------------

* House Description:

  • Ground Floor: Porch, Greet Hall, Kitchen, Balcony, Bedroom, Bathroom, Stair, and Garage.
  • First Floor: 4 Bedroom, 2 Bathroom, Balcony.
  •
  • Floor Size: 12.65 x13.65 Meter = (41.60 x 44.80 Feet)
  • Total Built-up Area: 261,00 M2 (2810 sq. ft)
  • (GF 139.00 + FF 122) M2
  • (GF 1495 + FF 1315) sq. ft

--------------------

* Drawings Description:

The Set of Designs and Drawings in PDF file in A3 Paper Size and its including the Following:

1- Floor plans: (2 Nos.) Ground Floor and First Floor plans, shows horizontal cutaway for all rooms, walls, windows, doors and the Furniture's with the Dimensions.

2- Furniture's Plan: (2 Nos.) Ground Floor and First Floor plans, Shows the Furniture's location and room sizes.

3- Elevations Plan: (2 Nos.) Front, Rear, Left and Right Elevation Shows the External views .

4- Sections Plan: (1 No.) A-A Shows a Vertical cutaway view with dimensions.

5- Roof Deck Location: (1 No.) Shows air view of the roof with valleys, hips, and ridges, slopes.

6- Roof Deck Plan: (1 No.) Shows air view of the roof with valleys, hips, and ridges, slopes.

7- Schedule: of Doors and Windows.

8- Typical Details:

9- Copyright Release: to have the Authority to use the Full Set of plans for your Personal use.

--------------------

* For Sale: The House plans are Ready in PDF file for Instant download, if you like to Buy them Click the Link:

https://www.etsy.com/uk/PanoramaHousePlans/listing/924306163
